Kegerator (kit de instalación)-Install Beer

Kegerator (installation kit)

PK0028

200.18€ EUR (242.21€ EUR IVA incl.)

Pickup available at Install Beer S.L.

Usually ready in 4 hours

Fast and secure shipping (24h express)

Flexible returns (14-day period)

3-year warranty (6 months for businesses)

Kegerator installation kit for fridge draft system

Enjoy the pleasure of a bar at home with the kegerator system. Easily install the mounting kit, serve one or two kegs, and save 60% compared to cans/bottles. Includes premium tap, tubing, and connectors for perfect service of your favorite beer.

The Kegerator is a complete home beer dispensing system (fridge not included). The beer keg is stored in a refrigerated container (fridge) to keep it cold. It allows you to dispense one or two kegs of beer from your own home or venue. Pour beer as if you were in a bar or brewery with the most economical option for dispensing beer from a keg.

Because a keg stores large quantities of beer, the kegerator manages to save more than 60% of the cost of beer compared with the same volume in cans and bottles.

Easy to install and maintain. You can choose a model with one or two beer taps and the required couplers (with 3/8" John Guest quick connector included). A CO2 cylinder or air compressor is required to draw the beer from the keg.

Fridge not included

The pack includes:

Stainless steel Kegerator plate
Drip tray
Alpha L55 beer tap with compensator JG 3/8" with collar and thread
Lupulus II 3/8" beer tube (1 m/2 m)
Poly SK 3/8" air/gas tube (2 m / 3 m)
John Guest Equal T Connector 3/8" (for gas or air)
Optional: Beer coupler head with 3/8" John Guest outlet

Kegerator* dimensions:

1 Tap: Width 21cm x Height 40cm (hole centered at 33cm height)
2 Taps: Width 38 cm x Height 40 cm (holes spaced 18 cm at 33 cm height)
Tab to hold the 16 cm wide x 10 cm long drip tray
Single drip tray 21x16x2.5 cm / Double drip tray 36x16x2.5 cm
1/2" (22mm) tap hole diameter

*To install the Kegerator, you must drill the desired surface with a 22 mm hole saw. You must also make a 3/8" (10 mm) diameter hole for the external air or CO2 tube.

Get inspired by the Kegerator image gallery

You might also like

Frequently asked questions

It depends on the type of connector/head, threads, and tube diameter. If you provide us with your configuration or send us a photo, we can confirm compatibility.

Thread type, inner/outer tube diameter, fitting type (quick-connect/barb/threaded), and whether it’s for beer, gas, or water line.

The description specifies what is included. If you need additional seals or accessories, we’ll recommend compatible options.

The material (stainless steel, brass, etc.) is designed for food-grade and dispensing use. If you’re going to use it with another beverage or under special conditions, we’ll advise you.

It’s usually a straightforward installation, but we recommend a clean cut on the tubing, proper tightening, and leak testing. We’ll indicate the method according to the type of connection.

The key is to identify your system’s thread standard and connection type. If you’re unsure, send us a photo of the current part and we’ll help you choose.

It’s usually due to a worn gasket, incorrect measurement, poorly cut tubing, or insufficient sealing. We’ll help you diagnose and fix it.

Yes, some components affect flow and stability. If you’re having issues with foam or flow rate, we’ll help you balance pressure, temperature, and line.

It depends on usage and cleaning, but it’s advisable to check them regularly to avoid leaks and maintain a stable, hygienic service.

Yes. We advise you before and after purchase and provide technical service. We also ship throughout Europe and to North, Central, and South America.
